When you go to do the final welds on everything, how to you figure out the correct caster for the front axle for it's ride height for the steering knuckles. You know what I mean? So when you turn the tires, it just turns them on an even plane; so it doesn't jack the truck up a little and flop it up and down as if your knuckle angles were off. You see on show trucks sometimes (the ones that keep their front driveshafts), a lot of the extremely tall ones have to cut and rotate their pigs to point up at the tcase cuz' the driveshaft angle gets fawked up. I don't plan on going so high I have to do that but when I put the 60 in there, I'd like for the steering knuckles to be balls on....know what I mean?
Here's the impression I was under on how to do this......assuming that the front flat surface of yur diff is prefectly vertical when yur at ride height....couldn't you just keep that level when designing your suspension as long as the knuckles were also perfectly vertical as well?
That brings me to another point. If you wanted to, couldn't you build a jig to hold yur axle so that the knuckles were perfectly level throughout the suspension design? Assuming that the knuckles on the axle were perfectly level when the pig was at a perfect 90 degree angle to the floor, would this make sense? Basically what I am thinking, is this. If I had the axle sitting there on a set of low jackstands or something, and I used a 2' carpenters square and got the axle so that the face of the pig (the flat surface where ya mount the diff cover) was vertical, and squared it off of the floor perfectly; would this work to set the knuckles? If you welded a jig up as long as you held it with the pigs face against one side of the 2' carpenters square and the other side against the floor while welding it?
If this method could work for the axle I have, sweet! But like anything, I don't think it's that easy at all, but I could be right. IF i am wrong, (which I probably am)....could someone point me in the right direction here?
I understand how if for example you have a 4 link with a adjustable upper(s) or lower(s)....you can make small changes that way, but I guess what I mean is where do I measure it from? How do you measure the caster so when I build links, they'll end up somewhere in the middle....not maxed out one way or another and still have room for adjustment....know what I mean?
I did a search for caster and all I found were a couple posts about the specs and tolerances that caster should be within for certain axles....

If anyone has any idea wtf I'm talkin about, post up! I'm all ears on this one.
Zach
