PlumCrazy's Build

[PlumCrazy]

I never actually tried the SOHC pan in the TTB cross member though. I know some guys just shim the motor up .5" or so and it clears from what I hear.

Sent from my XT907 using Crapatalk



[escort_gts]

So are you going to get it done by this fall?

Sent from my SM-N910T using Tapatalk



[PlumCrazy]

Hope so. Dropped the block off today for machine work

Sent from my XT907 using Crapatalk



[RangerSVT]

I'm hoping to get mine (HWW) done by the 4th of july if not sooner. It's been a while since I've been on the trails...

SVT



[escort_gts]

Rick, you and Dustin get them running and I'll come down and wheel with you both

Sent from my SM-N910T using Tapatalk



[PlumCrazy]

Made a little progress...

Burned out a flange for the new exhuast out of .5" plate. Still np ETA on the block though.

Also got the track bar whacked off....then I changed gears and started the OneFiddy 5 speed swap.

Also elimnated the fire hazard insulation on the HVAC plenum....pulled the old stuff off and bent up some aluminum to replace it.

Seals for the SOHC oil pan showed up too



[PlumCrazy]

Started toying with the idea of adding some lubrication to the pushrod end of the rockers.

Using some 1/4" OD tube and sweat on fittings I built a manifold that will pull oil from around the rocker shaft mounting bolt and drip over the rocker end.

I ordered some sweat on banjo fittitings, but they only come in 3/16". I drilled them to 1/4" and sweat everything together with 430* silver solder.

I clamped an air hose on plugged the holes to test for leaks under water..

Still need to drill the orifice oils for each rocker, then I will clean the inside and cap the ends. I will need to turn the shank of the bolt down a touch to allow oil to flow into the banjo. I will also be adding support brackets on the other two bolts...

I am using a high volume oil pump, so I should have more than enough flow without giving up any oil pressure. I also plan to safety wire the fittings and tubes just incase something fatigues and breaks.

I need to do a little math to figure out what size holes to put over each rocker. Im thinking .0125" should be good. The oil may or or may not even make it into the socket though....but I suppose extra oil showering on the rockers cant hurt anything.lol



[wizkid00104]

Impressive. What on earth sparked this idea???



[escort_gts]

Impressive. What on earth sparked this idea???

Yeah, I was thinking the same thing

Sent from my SM-N910T using Tapatalk



[PlumCrazy]

I hate valve noise...and I was bored.lol



[wizkid00104]

I feel like you are the closest thing we have to a real Tony Stark.... So when will your Mark I Iron Man suit be completed?



[RangerSVT]

Hows the progress coming? Heard from the machine shop?

SVT



[adsm08]

Started toying with the idea of adding some lubrication to the pushrod end of the rockers.

Using some 1/4" OD tube and sweat on fittings I built a manifold that will pull oil from around the rocker shaft mounting bolt and drip over the rocker end.

I ordered some sweat on banjo fittitings, but they only come in 3/16". I drilled them to 1/4" and sweat everything together with 430* silver solder.

I clamped an air hose on plugged the holes to test for leaks under water..

Still need to drill the orifice oils for each rocker, then I will clean the inside and cap the ends. I will need to turn the shank of the bolt down a touch to allow oil to flow into the banjo. I will also be adding support brackets on the other two bolts...

I am using a high volume oil pump, so I should have more than enough flow without giving up any oil pressure. I also plan to safety wire the fittings and tubes just incase something fatigues and breaks.

I need to do a little math to figure out what size holes to put over each rocker. Im thinking .0125" should be good. The oil may or or may not even make it into the socket though....but I suppose extra oil showering on the rockers cant hurt anything.lol



[PlumCrazy]

Hows the progress coming? Heard from the machine shop?

SVT

Pretty much absolutely zero progress.....No word from the machine shop.

PS....your headers are in the trunk of my car...I put them there to take to work and box up.....2 weeks ago. I swear Ill get them out to you.lol



[RangerSVT]

Oh yeah, I forgot all about them. I'm about to start up on that project next week actually...

SVT
