Ranger Body on F-series Chassis???

[bigredrangerxlt]

I picked up an 87 std. cab, long bed 4x4 with manual tranny and 2.9L (mint. Body). I want to swap in a 351W, 460, or...7.3L Diesel with a manual tranny/t-case and axles from an F-350 (basically the entire rolling chassis). Has anyone tried swapping a ranger body onto a full size chassis??? If so what was all involved? I am assuming new body mounts inboard of the F-350 frame rails would be necessary, frame shortening along with new drive shafts and steering modifications. I am figuring on purchasing a complete donor F-350 with a trashed body and good running gear to complete the swap. Ideally I would also use all of the F-350 wiring. Thanks in advance for your input.



[cammeddrz]

Has anyone tried swapping a ranger body onto a full size chassis???.

not a ranger but a broncoII. and
not a ford chassis but a chevy
http://broncoii.org/forum/index.php?topic=9152.0

but a ford full width chassis is just as different from an rbv as a chev chassis is.

i shortened the frame, built my mounts (which didn't need to be "inboard" just closer to the frame), cut a hole in the floor to let the shifters through, i made a steering shaft with 2 u-joints to combat the box being in a different place, adapted the throttle cable, and welded brackets to the body to hold the radiator from the full-size.

that was about all it took
here is the frame before i set the body on to it a year and a half ago(see the mouts i built):



[xkotyx]

i saw a ranger once that was on an old f100 chassis



[kris97ranger]

Its been done quite a few times I've seen on here with full size broncos and f 150s it works fairly well just measure where you want your fenderwells to be over the wheels. In an ideal world you will get lucky and the tires match up them you just make your body mounts and deal with whatever frame sticks out front and back at least that's how I've sen people do it. I cannot remember the name of the guy now but he's on here with a 2nd gen ranger on a f150 frame 460 big block and 42" cut boggers



[--weezl--]

me would tihnks that a short/short f-150 would have close to the same wheel base as a supercab long box ranger... if the ranger wasn't longer than the f-150...

the 350's shouldn't be much different, length wise, than the 150, and worst case senario, if you took a super cab long box ranger, you can always shorten the box if that body is too long...

i think it would be a wicked project, just PLEASE!!!! don't do what some of the guys on here do, and that's when you do your build thread for an epic build like this, don't start on it, get us all interested and wait 6 months before doing more, because that's like foreplay and blueballs... if you're going to do it, get-er dun as fast as possible for our sake (and yours i suppose too)



[rangerdestroyer]

ya im thinking of doing that kinda build to. i got an 1988 F150 2wd converted to 4x4 long box reg cab, im going to be putting a 1984 ranger ext. cab short box on the frame????? its going to be a fun build
